【中古】【2022年モデル】Checkpoint ALR 5
【中古】【2022年モデル】Checkpoint ALR 5
Original retail price: ¥296,890 (at the time of sale, tax included)
Used condition:★★★☆☆(中程度)
Low stock
Couldn't load pickup availability
Item number: SKU:496609094628368(-33260826)
■ Domestic Shipping Fee Estimate
Overview
【中古美品】TREK Checkpoint ALR 5 2022年モデル。軽量アルミフレームにShimano GRX 2×11速と油圧ディスクブレーキを搭載。グラベルライドやバイクパッキング、街乗りまで幅広く楽しめます。チューブレスレディからチューブドへ変更 | 前後ブレーキキャリパー新品交換 | バーテープ新品交換 | サドル新品交換 | チェーン新品交換 | 前後タイヤチューブ新品交換
- Product Description
- Specifications
- Geometry (Size)
- Returns, Delivery & Shipping
TREK Checkpoint ALR 5 2022年モデル【中古】|旅にも日常にも応えるアルミグラベルロード
舗装路を軽快に走り、そのまま未舗装路やキャンプツーリングへ。行き先を決めすぎずに遊べる、定番アルミグラベルロード。
休日のグラベルライドから、バッグに道具を詰め込んで出かけるバイクパッキング、毎日の街乗りまで。TREK Checkpoint ALR 5は、ひとつの用途に縛られず、さまざまな道と過ごし方を楽しめる一台です。
上位グレードのSL/SLRと同じくプログレッシブジオメトリーを採用し、機敏なハンドリングと直進時の安定感を両立。ダウンチューブやトップチューブ、フロントフォークなどに豊富なマウントを備え、ボトルやバッグを組み合わせた積載スタイルにも対応します。
こちらは使用感の少ない中古美品です。フロントフォークと右クランクに傷がございますので、状態については掲載写真もあわせてご確認ください。
特徴
- 軽量性と耐久性を備えた300 Series Alpha Aluminumフレーム
- 機敏な操作感と直進安定性を両立するプログレッシブジオメトリー
- トップチューブやダウンチューブ下、フロントフォークなどに豊富な積載用マウントを配置
- 幅広いギア比を選べるShimano GRX 2×11速ドライブトレイン
- 天候や路面状況を問わず制動力をコントロールしやすい油圧ディスクブレーキ
- 最大700×45Cタイヤに対応するタイヤクリアランス
- Panaracer GRAVELKING + TLR 700×35Cを装着したチューブド仕様
- 27.2mm径の内装式ドロッパーシートポストに対応
SPEC
- 年式:2022年モデル
- フレーム:300 Series Alpha Aluminum
- フォーク:Checkpoint、カーボンレッグ
- クランクセット:Shimano GRX RX600
- フロントディレーラー:Shimano GRX RX810
- リアディレーラー:Shimano GRX RX810
- ブレーキ:Shimano GRX 油圧ディスクブレーキ
- 最大タイヤクリアランス:700×45C
- サイズ:52
- 適応身長目安:166~172cm
- 状態:中古 美品
- キズ箇所:フロントフォーク、右クランク
アルミグラベルロードの中でも、積載用マウントの多さと走りのバランスが魅力的なモデルです。普段は軽快なロードバイクとして使いながら、休日にはバッグを取り付けて林道やキャンプツーリングへ向かう、といった使い方にもよく合います。
GRXのフロントダブル仕様は、舗装路で速度を出したい場面から荷物を積んだ状態での登りまで、細かくギアを選びやすい構成です。
スペック表
| タイヤサイズ | 700c | |
| 変速数 | 2×11speed | |
| ペダル | 無 | |
| スペック | フレーム | 300 Series Alpha Aluminum、 tapered head tube、 Internal cable routing、 3S chain keeper、 T47 BB、 rack and fender mounts、 integrated frame bag mounts、 flat mount disc、 142x12mm thru axle |
| フォーク | Checkpoint、 carbon legs、 tapered alloy steerer、 rack mounts、 fender mounts、 flat mount disc、 12x100mm thru axle | |
| クランクセット | Shimano GRX RX600、 46/30、 170mm length | |
| BB | Praxis、 T47 threaded、 internal bearing | |
| Fメカ | Shimano GRX RX810、 braze-on | |
| Rメカ | Shimano GRX RX810、 long cage、 34T max cog | |
| シフター | Shimano GRX RX600、 11 speed | |
| スプロケット | Shimano 105 HG700-11、 11-34、 11 speed | |
| ブレーキレバー | Shimano GRX RX600、 11 speed | |
| ブレーキ | Shimano GRX, Shimano SM-RT70、 centerlock、 160mm | |
| タイヤ | Panaracer GRAVELKING + TLR 700×35c | |
| ホイール | F.hub:Bontrager alloy、 sealed bearing、 centerlock disc、 100x12mm thru axle F.skewer:Bontrager Switch thru axle、 removable lever R.hub:Bontrager alloy、 sealed bearing、 centerlock disc、 Shimano 11-speed freehub、 142x12mm thru axle R.skewer:Bontrager Switch thru axle、 removable lever Rim:Bontrager Paradigm SL、 Tubeless Ready、 24-hole、 21mm width、 presta valve Spoke:14g stainless steel | |
| ハンドル | Bontrager Elite Gravel、 40cm width | |
| ステム | Bontrager Elite、 31.8mm、 Blendr compatible、 7 degree、 80mm length | |
| ヘッドセット | FSA Integrated、 sealed cartridge bearing、 1-1/8" top、 1.5" bottom | |
| サドル | GIZA VL-1533 | |
| シートポスト | Bontrager alloy、 27.2mm、 12mm offset、 330mm length | |
フレームジオメトリー

| フレームサイズ | 52 |
| HA | 71.6 |
| SA | 73.7 |
| TT | 555 |
| HT | 105 |
| FC | - |
| RC | 435 |
| BB | 71 |
| FO | 45 |
| WB | 1033 |
| SH | 765 |
| SK | 553 |
| RH | 399 |
| 適応身長 | 166-172cm |
